    Advertising Series CO2 Laser Engraving Cutting Machine Water Cooling For Bamboo Gift

    Advertising Series Co2 Laser Engraving Machine For Bamboo Gift

    Product Features

    1. CO2 Laser cutting/engraving machines series are very popular in the market around the world. 2.high stability and accuracy. Quality and price ratio is high.
    3. Using stepper motor and driving system imported from USA.
    4. LCD, PCB lamp motherboard, USB port
    5. Water-cooling system, domestic -made 70W CO2 Laser
    6. Origional straight-line-guiding-track from Japan.


    Application

    Clothing,footwear,luggage,computerized embroidery and clipping, model, electronic appliance, toys, furniture, advertisement decoration,packaging, printing,paper products,handicrafts and other industries.


    Applied Material:

    Wood work, paper, leather, cloth, organic glass, resin, acrylic, woolens, plastic, rubber, ceramic, crystal, jade, bamboo and other non-metal materials.


    Specifications


    Item:LX-1390
    Laser Type:CO2 Laser Tube
    Laser Wavelength:10.64um
    Laser Power:60W/80W/100W/130W/150W/180W
    Working Area:600*900mm/1300*900mm/1600*1000mm
    Engraving Speed:0-30000mm/min
    Cutting Speed:0-3600 mm/min
    Cutting Thickness0-10mm (Varies to different materials)
    Machine Power:300-450W
    Location Type:Red Pointer positioning
    Location Accuracy±0.1mm
    Resolution:1000dpi
    Port:USB 2.0
    Working Table:Honeycomb table
    Up-down height:0-300mm
    Mini Text Height:English Letter: 1mm Chinese:2mm
    Support Software:Windseal XP / CorelDraw
    Working Voltage:AC220V/50HZ AC110V/50HZ
    Working Environment:Temperature:0-45℃ Humidity:5%-95%
    Driver Way:Digital Subdividing Step Driver
    Laser Device Cooling TypeCirculating Water Cooling
    Option Item:

    Motorized up-down table, Rotary Fixture

    Water-circulation Non-normal Protection Switch,

    CW-3000 Water Chiller

    Rotary System(Optional)φ10-150×300mm




    Sample show




    Packaging & Delivery

    1. Wood case or as per required.
    2. The delivery lead time would be 7-15 days against down payment.
    3. As for the wholsalers/distributors,we could send the cargo by air, by sea or by railways via reliable forwarder

    Competitive Advantages

    1. We offer high quality products at competitive price in quick delivery.
    2. 100% custom pass guaranteed.
    3. Good after-sale service.
    4. Flexible and Untraceable payment terms.
