110V 50HZ Laser Coding System With LCD Touching For Keyboard & Laptop Letter Characters

    Buy cheap 110V 50HZ Laser Coding System With LCD Touching For Keyboard & Laptop Letter Characters from wholesalers

    Buy cheap 110V 50HZ Laser Coding System With LCD Touching For Keyboard & Laptop Letter Characters from wholesalers
    • Buy cheap 110V 50HZ Laser Coding System With LCD Touching For Keyboard & Laptop Letter Characters from wholesalers

    110V 50HZ Laser Coding System With LCD Touching For Keyboard & Laptop Letter Characters

    Ask Lasest Price
    Brand Name : Linxuanlaser
    Model Number : LX-A3
    Certification : CE certification
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal
    Supply Ability : 150 units one month
    Delivery Time : 7 working days
    • Product Details
    • Company Profile

    110V 50HZ Laser Coding System With LCD Touching For Keyboard & Laptop Letter Characters

    110V 50HZ Laser Coding System With LCD Touching For Keyboard & Laptop Letter Characters





    Product Description

    LX-A3 series laser marking machine (online flying marker), adopted imported laser SOURCE and equipped with imported high-speed galvanometer scanning system, triggered by the electro-optical sensors to signal laser marking job, using professional online flight marking control software enable it mark products online. Laser code spraying machine can be directly matched with factory assembly line, 24-hour continuous operation, ensure production efficiency greatly, with low power consumption and without consumables





    Application Field and Material

    Bamboo and wood products, papers, fabric, leather, organic glass, epoxy resin, acrylic, polyester resin.Arts and crafts, furniture, leather and costume, advertising label, model making, food packaging, electronic components, medicine packaging, printing plate making, shell label, etc

    Features of Laser Marking Solution LX-A3:

    1. Fiber laser, Basic model, high speed galvo scanner; IPG laser and Chinese Brand laser for option.
    2. Maintenance Free, save equipment and worker cost;
    3. Imported Galvonometer, Higher precision,faster speed;
    4. Higher photoelectric conversion efficiency, Low power consumption;
    5. Red light preview, more accurate and reduce positioning time;
    6. Laptop with Powerful marking software;
    7. User friendly software interface, easy operation;
    8. Set and deal different layers graphic separately;
    9. Support PLT,PCX,AL,DXF, BMP,JPG formats file;
    10. Compatible AutoCAD,CorelDraw,Photoshop etc software Automatic serialization,date coding letter, symbol, pattern, figure, image, bar code, 2D code auto arrangement and amendment.





    Technical Parameter for blue color table fiber laser marking machine
    Parameters

    ModelLX-A2
    Output Power50W
    Laser Wave Length1064mm
    Laser Ray Mass<1.4
    Adjustable Laser Frequency20KHz~100KHz
    Marking Size110x110mm/300x300mm
    Marking Depth0-1mm
    Minimum Line Width0.01mm
    Re-marking Precision±0.001mm
    PowerAC220V/50Hz
    Whole Power Consumption500W
    Marking Speed500c/s (Single Line Character in 1mm Height)
    Machine Dimension820mm*420mm*560mm
    Cooling WayAir Cooling





    Optional accessory
    1 set of marking control system
    1 laptop
    1 marking work table
    1 red laser pointer
    1 pedal switch
    1 set of marking software
    1 user manual



    After sales service

    Training Service
    Our technician is available to your factory and offer training of how to use our machines.
    As well, you may send your technician to our company to learn how to operate machines.
    Quality Guarantee
    We arrange final test before shipment. We run the machine without material for a few days,
    and then cut materials for test. After making sure machine is the best performance, then ship
    out the machine.
    Operating guide
    Explain the use of machines and software. Guide the customer proper use, extend product life
    and reduce energy consumption.
    Machine maintenance&Warranty
    Explain the maintenance of machine parts to extend product life and save the energy consumption,The whole set of machine warranty period is 2 year.



    Packaging & Delivery

    1. Standard plywood case, its compressive strength and bearing quality is better.
    2. the board area is bit, the soil structure is good, it is better in leakproofness and waterproof.
    3. when importing, the plywood case is with fumigation-free, the procedure is simple.
    4. Delivery Detail: within 7-14 days after received your payment
