Mini CNC Engraving Machine , CNC Wood Carving Machine With Steady Data Transmission

    Buy cheap Mini CNC Engraving Machine , CNC Wood Carving Machine With Steady Data Transmission from wholesalers

    Buy cheap Mini CNC Engraving Machine , CNC Wood Carving Machine With Steady Data Transmission from wholesalers
    • Buy cheap Mini CNC Engraving Machine , CNC Wood Carving Machine With Steady Data Transmission from wholesalers

    Mini CNC Engraving Machine , CNC Wood Carving Machine With Steady Data Transmission

    Ask Lasest Price
    Brand Name : Linxuan
    Model Number : cnc router machine
    Certification : CE FDA
    Price : USD 3000-30000 per set
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 50sets per month
    • Product Details
    • Company Profile

    Mini CNC Engraving Machine , CNC Wood Carving Machine With Steady Data Transmission

    Mini CNC Router Engraving Milling Machine With Steady Data Transmission For Wood Working


    1. Applicable industry and materials of cnc router:

    Wooden door and furniture decoration, wooden crafts processing, electronic product, instrument industry, etc.

    Wood, MDF, PVC, PCB, Acrylic, Circuit board, Aluminum, Copper etc.

    Engrave on material surface, 3d engraving on violin panel, making guitar, erhu etc.

    Technical Parameter :

    Working area:600x900x100mm
    Spindle type:Water cooled spindle
    Spindle power1.5kw
    Spindle rotating speed0-24000rpm
    Power supply:AC220±10, 50 HZ
    Worktable:T-slot table /Vacuum table
    Locating precision:<0.01mm
    Min shaping character:Character:3x3mm,letter:2x2mm
    Operating temperature:5°C-40°C
    Working humidity30%-75%(without condensed water)
    Working precision±0.03mm
    System resolution±0.001mm
    Control configuration:Mach3/DSP/ NC studio control system
    Data transfer interface:USB/PC
    System environment:WINDOWS 2000/WINDOWS XP/ windows 7
    Spindle cooling way:Water cooling by water pump (optional: chiller)
    Graphic format supported:G code: *.u00, * mmg, * plt, *.nc
    Compatible softwareARTCAM, UCANCAM ,Type3 and other CAD or CAM softwares….
    Cutting thickness:0-40mm also (depends on different material)
    Z tool sensor:yes
    Whole machine dimension:1500x980x1450mm
    Net weight:280KG
    Gross weight350KG
    packingPlywood case (veneer wood case for export)
    Optional parts1. Water cooled type spindle (China brand or Italian brand)
    2. Bigger or smaller power spindles (6kw or 3kw)
    3. High-grade cooling system (chiller, it has alarming system)
    4. double-head or more heads
    5. servo motors (China brand or Japan brand)
    6. Auto tool change system
    (this system need other systems accordingly, like LNC control system, servo motors etc)
    7. Weihong DSP Control system ,NK105 Model or Mach 3
    8. other customerized features.
