Wine Glass Bottle Engraving Machine , 900 * 600mm Co2 Laser Wood Engraving Machine

    Buy cheap Wine Glass Bottle Engraving Machine , 900 * 600mm Co2 Laser Wood Engraving Machine from wholesalers

    Buy cheap Wine Glass Bottle Engraving Machine , 900 * 600mm Co2 Laser Wood Engraving Machine from wholesalers
    • Buy cheap Wine Glass Bottle Engraving Machine , 900 * 600mm Co2 Laser Wood Engraving Machine from wholesalers

    Wine Glass Bottle Engraving Machine , 900 * 600mm Co2 Laser Wood Engraving Machine

    Ask Lasest Price
    Brand Name : Linxuan
    Model Number : LX-1610
    Certification : CE FDA
    Price : USD 3000-8000 set
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 50 sets per month
    Delivery Time : 5-15 working days
    • Product Details
    • Company Profile

    Wine Glass Bottle Engraving Machine , 900 * 600mm Co2 Laser Wood Engraving Machine

    Wine Glass Bottle Engraving Machine Co2 Laser Wood Pic Engraver Machine 900*600mm

    Product Features

    1. All set imported metal sealed laser system, easy to install and operation.

    2. High precision, high speed, marking clear, strong permanent

    3. Low power consumption, cost effective and long life, convenient to maintenance.

    4. Integrated and compact structure

    5. Imported metal tube, stable and long life.

    6. Versatile marking software is compatible with Coreldraw,AutoCAD,Photoshop.


    Application

    1. Double-colored board and Label carving, Organic glass carving and cutting

    2. Carved gifts and Crafts industry: wood/Granite, Bamboo, Ivory, Bone, Leather

    3. Leather clothing industry: Complex characters and pattern carving,Synthetic Leather, Man-made Leather, Cloth.

    4. Arcitectural model industry: ABS board cutting, Model carving

    5. Packing and Printing Industry: Rubber,Plastic board, Double-layered board, Model cutting board.


    Applied Material:

    Wood work, paper, leather, cloth, organic glass, resin, acrylic, woolens, plastic, rubber, ceramic, crystal, jade, bamboo and other non-metal materials.


    Specifications


    Item:LX-1390
    Laser Type:CO2 Laser Tube
    Laser Wavelength:10.64um
    Laser Power:60W/80W/100W/130W/150W/180W
    Working Area:600*900mm/1300*900mm/1600*1000mm
    Engraving Speed:0-30000mm/min
    Cutting Speed:0-3600 mm/min
    Cutting Thickness0-10mm (Varies to different materials)
    Machine Power:300-450W
    Location Type:Red Pointer positioning
    Location Accuracy±0.1mm
    Resolution:1000dpi
    Port:USB 2.0
    Working Table:Honeycomb table
    Up-down height:0-300mm
    Mini Text Height:English Letter: 1mm Chinese:2mm
    Support Software:Windseal XP / CorelDraw
    Working Voltage:AC220V/50HZ AC110V/50HZ
    Working Environment:Temperature:0-45℃ Humidity:5%-95%
    Driver Way:Digital Subdividing Step Driver
    Laser Device Cooling TypeCirculating Water Cooling
    Option Item:

    Motorized up-down table, Rotary Fixture

    Water-circulation Non-normal Protection Switch,

    CW-3000 Water Chiller

    Rotary System(Optional)φ10-150×300mm




    Sample show






    Packaging & Delivery

    1. Wood case or as per required.
    2. The delivery lead time would be 7-15 days against down payment.
    3. As for the wholsalers/distributors,we could send the cargo by air, by sea or by railways via reliable forwarder

    Competitive Advantages

    1. We offer high quality products at competitive price in quick delivery.
    2. 100% custom pass guaranteed.
    3. Good after-sale service.
    4. Flexible and Untraceable payment terms.
